- Datasheet Download Datasheet
- Stock & Prices $ Price & Stock for DS2438Z+
- Part Number DS2438Z+
- Manufacturer Analog Devices
- Pin Count 8
- Part Category Integrated Circuit
- Package Category Small Outline Packages
- Footprint Name Small Outline Packages - soic8-ren3
- Released Date Jan 25, 2016
- Last Modified Date Mar 7, 2023 4:10 PM UTC
- Pinout / Pin List Click Here (Member Only)
DS2438Z+ Details
-
Manufacturer Part Number:
DS2438Z+
-
Brand Name:
Analog Devices Inc
-
Rohs Code:
Yes
-
Part Life Cycle Code:
Active
-
Part Package Code:
8-SOIC_N-150_MIL
-
Package Description:
0.150 INCH, LEAD FREE, SOIC-8
-
Pin Count:
8
-
Manufacturer Package Code:
8-SOIC_N-150_MIL
-
Country Of Origin:
Japan, Mainland China, Malaysia, Philippines, Singapore, South Korea, Taiwan, Thailand, USA
-
ECCN Code:
EAR99
-
HTS Code:
8542.39.00.60
-
Date Of Intro:
2002-08-09
DS2438Z+ Frequently Asked Questions (FAQs)
-
The recommended layout and routing for the DS2438Z+ involves keeping the analog and digital grounds separate, using a solid ground plane, and minimizing the length of the traces between the device and the battery. It's also important to avoid running digital signals near the analog signals.
-
To ensure accurate temperature measurements, it's essential to follow proper thermal design practices, such as placing the device in close proximity to the thermal source, using a thermally conductive material, and minimizing thermal gradients. Additionally, calibrating the device and using the built-in temperature correction feature can improve accuracy.
-
The maximum battery life of the DS2438Z+ depends on various factors, including the battery type, capacity, and operating conditions. However, with a typical coin-cell battery, the device can operate for up to 10 years or more, depending on the sampling rate and transmission frequency.
-
Yes, the DS2438Z+ can be used in a multi-battery configuration, but it requires careful consideration of the battery connections and charging/discharging cycles. It's essential to ensure that the batteries are properly connected and balanced to avoid overcharging or undercharging, which can affect the device's performance and battery life.
-
To troubleshoot communication issues with the DS2438Z+, start by checking the device's power supply, clock frequency, and data transmission rate. Verify that the device is properly configured and that the communication protocol is correctly implemented. Use a logic analyzer or oscilloscope to debug the communication signals and identify any errors or anomalies.
Trust Checks
Community Provided
System Verified
Community Approved
DS2438Z+ Overview
Use the download button to access the DS2438Z+ schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like DS243,
or try a keyword search, such as Power Management Circuits
About Analog Devices
Analog Devices Inc. is a global leader in the design and manufacturing of analog, mixed-signal, and digital signal processing integrated circuits and software solutions for the industrial, automotive, healthcare, communications industries. Analog Devices serves a diverse range of markets including industrial, automotive, healthcare, energy, aerospace, defense, and consumer electronics industries.
Analog Devices’ product portfolio includes a wide range of ICs, modules, and subsystems.
