- Part Number DS2502S+T&R
- Manufacturer Analog Devices
- Pin Count 8
- Part Category Integrated Circuit
- Package Category Small Outline Packages
- Footprint Name Small Outline Packages - S8+2
- Released Date Oct 2, 2020
- Last Modified Date Jan 7, 2026 2:49 PM UTC
- Pinout / Pin List Click Here (Member Only)
DS2502S+T&R Details
-
Manufacturer Part Number:
DS2502S+T&R
-
Brand Name:
Analog Devices Inc
-
Rohs Code:
Yes
-
Part Life Cycle Code:
Active
-
Part Package Code:
8-SOIC_N-150_MIL
-
Package Description:
SOP, SOP8,.25
-
Pin Count:
8
-
Manufacturer Package Code:
8-SOIC_N-150_MIL
-
Reach Compliance Code:
Compliant
-
Country Of Origin:
Japan, Mainland China, Malaysia, Philippines, Singapore, South Korea, Taiwan, Thailand, USA
-
ECCN Code:
EAR99
-
HTS Code:
8542.32.00.61
