DS75U+ - Analog Devices

DS75U+ Details

• Manufacturer Part Number:

  DS75U+

• Brand Name:

  Analog Devices Inc

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  8-MINI_SO-N/A

• Pin Count:

  8

• Manufacturer Package Code:

  8-MINI_SO-N/A

• Country Of Origin:

  Japan, Mainland China, Malaysia, Philippines, Singapore, South Korea, Taiwan, Thailand, USA

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Date Of Intro:

  2003-02-21

• Manufacturer:

  Analog Devices Inc

• YTEOL:

  8.5

• Accuracy-Max (Cel):

  2 Cel

• Body Breadth:

  3 mm

• Body Height:

  1.1 mm

• Body Length or Diameter:

  3 mm

• Housing:

  PLASTIC

• JESD-609 Code:

  e3

• Mounting Feature:

  SURFACE MOUNT

• Number of Bits:

  12

• Number of Terminals:

  8

• Operating Current-Max:

  1 mA

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Output Interface Type:

  2-WIRE INTERFACE

• Package Body Material:

  PLASTIC/EPOXY

• Package Equivalence Code:

  TSSOP8,.19

• Package Shape/Style:

  SQUARE

• Sensors/Transducers Type:

  TEMPERATURE SENSOR,THERMOMETERS

• Supply Voltage-Max:

  5.5 V

• Supply Voltage-Min:

  2.7 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Terminal Finish:

  Matte Tin (Sn) - annealed

• Termination Type:

  SOLDER
