DSC1001CI5-008.0000 - Microchip

DSC1001CI5-008.0000 Details

• Manufacturer Part Number:

  DSC1001CI5-008.0000

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  QFN-4

• Pin Count:

  4

• Manufacturer Package Code:

  VDFN-4

• Country Of Origin:

  Thailand

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.01

• Factory Lead Time:

  13 Weeks

• Manufacturer:

  Microchip Technology Inc

• YTEOL:

  18

• Additional Feature:

  ALSO OPERATES AT 2.5V AND 1.8V SUPPLY VOLTAGE

• Fall Time-Max:

  2 ns

• Frequency Adjustment-Mechanical:

  NO

• Frequency Stability:

  10%

• JESD-609 Code:

  e4

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  4

• Operating Frequency-Nom:

  8 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Oscillator Type:

  CMOS

• Output Load:

  10 KOHM, 15 pF

• Package Body Material:

  PLASTIC/EPOXY

• Package Equivalence Code:

  SOLCC4,.01,83

• Physical Dimension:

  3.2mm x 2.5mm x 0.9mm

• Rise Time-Max:

  2 ns

• Screening Level:

  AEC-Q100

• Supply Current-Max:

  12.2 mA

• Supply Voltage-Max:

  3.6 V

• Supply Voltage-Min:

  1.7 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Symmetry-Max:

  55/45 %

• Terminal Finish:

  Nickel/Palladium/Gold (Ni/Pd/Au)
