DSM7UA30101 - Visual Communications Company

Description: LED Displays & Accessories Ultra Thin Display 1 dig .3 in RED

Download DSM7UA30101 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
DSM7UA30101 - Visual Communications Company PCB footprint - Other - Other - DSM7UA30101-2
click to zoom
3D Models
DSM7UA30101 - Visual Communications Company  - 3D model - Other - DSM7UA30101-2
click to zoom

DSM7UA30101 Details

  • Manufacturer Part Number:

    DSM7UA30101

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Country Of Origin:

    Taiwan

  • ECCN Code:

    EAR99

  • HTS Code:

    8541.40.60.50

  • Manufacturer:

    Visual Communications Company

  • YTEOL:

    6.52

  • Optoelectronic Device Type:

    7 SEG NUMERIC LED DISPLAY
