DZ23C4V7 - PANJIT

DZ23C4V7 Details

• Manufacturer Part Number:

  DZ23C4V7

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  ROHS COMPLIANT, PLASTIC PACKAGE-3

• Pin Count:

  3

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.50

• Manufacturer:

  PanJit Semiconductor

• YTEOL:

  6.95

• Configuration:

  COMMON CATHODE, 2 ELEMENTS

• Diode Element Material:

  SILICON

• Diode Type:

  ZENER DIODE

• JESD-30 Code:

  R-PDSO-G3

• Number of Elements:

  2

• Number of Terminals:

  3

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -65 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Polarity:

  UNIDIRECTIONAL

• Power Dissipation-Max:

  0.3 W

• Qualification Status:

  Not Qualified

• Reference Voltage-Nom:

  4.7 V

• Surface Mount:

  YES

• Technology:

  ZENER

• Terminal Form:

  GULL WING

• Terminal Position:

  DUAL

• Voltage Tol-Max:

  4.99%
