E-TDA7563 - STMicroelectronics

E-TDA7563 Details

• Manufacturer Part Number:

  E-TDA7563

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  ZFM

• Package Description:

  ROHS COMPLIANT, FLEXIWATT-27

• Pin Count:

  27

• ECCN Code:

  EAR99

• HTS Code:

  8542.33.00.01

• Manufacturer:

  STMicroelectronics

• YTEOL:

  0

• Bandwidth-Nom:

  22 kHz

• Consumer IC Type:

  AUDIO AMPLIFIER

• Gain:

  30 dB

• Harmonic Distortion:

  10%

• JESD-30 Code:

  R-PZFM-T27

• Number of Channels:

  4

• Number of Functions:

  1

• Number of Terminals:

  27

• Output Power-Nom:

  46 W

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  ZFM

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Qualification Status:

  Not Qualified

• Supply Voltage-Max (Vsup):

  18 V

• Supply Voltage-Min (Vsup):

  8 V

• Surface Mount:

  NO

• Technology:

  BCDMOS

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  ZIG-ZAG
