ECH8668-TL-H - onsemi

ECH8668-TL-H Details

• Manufacturer Part Number:

  ECH8668-TL-H

• Brand Name:

  onsemi

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  SOT-28FL / ECH8

• Package Description:

  HALOGEN AND LEAD FREE, ECH8, 8 PIN

• Pin Count:

  8

• Manufacturer Package Code:

  318BF

• ECCN Code:

  EAR99

• Manufacturer:

  onsemi

• YTEOL:

  0

• Configuration:

  SEPARATE, 2 ELEMENTS WITH BUILT-IN DIODE

• DS Breakdown Voltage-Min:

  20 V

• Drain Current-Max (ID):

  7.5 A

• Drain-source On Resistance-Max:

  0.017 Ω

• FET Technology:

  METAL-OXIDE SEMICONDUCTOR

• Feedback Cap-Max (Crss):

  135 pF

• JESD-30 Code:

  R-PDSO-F8

• JESD-609 Code:

  e6

• Moisture Sensitivity Level:

  1

• Number of Elements:

  2

• Number of Terminals:

  8

• Operating Mode:

  ENHANCEMENT MODE

• Operating Temperature-Max:

  150 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  260

• Polarity/Channel Type:

  N-CHANNEL AND P-CHANNEL

• Power Dissipation-Max (Abs):

  1.5 W

• Pulsed Drain Current-Max (IDM):

  40 A

• Surface Mount:

  YES

• Terminal Finish:

  Tin/Bismuth (Sn/Bi)

• Terminal Form:

  FLAT

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  30

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON
