ECX-H37CN-150.000 - ECS

ECX-H37CN-150.000 Details

• Manufacturer Part Number:

  ECX-H37CN-150.000

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  SMD, 6 PIN

• Factory Lead Time:

  10 Weeks

• Manufacturer:

  ECS International Inc

• YTEOL:

  6.44

• Additional Feature:

  ENABLE/DISABLE FUNCTION

• Fall Time-Max:

  1.5 ns

• Frequency Adjustment-Mechanical:

  NO

• Frequency Stability:

  25%

• JESD-609 Code:

  e4

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  6

• Operating Frequency-Nom:

  150 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Oscillator Type:

  HCMOS

• Output Load:

  15 pF

• Package Body Material:

  CERAMIC

• Physical Dimension:

  7.0mm x 5.0mm x 1.7mm

• Rise Time-Max:

  1.5 ns

• Supply Voltage-Max:

  3.63 V

• Supply Voltage-Min:

  2.97 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Symmetry-Max:

  48/52 %

• Terminal Finish:

  Gold (Au) - with Nickel (Ni) barrier
