ECX2-LMV-3CM-156.250-TR - ECS

ECX2-LMV-3CM-156.250-TR Details

• Manufacturer Part Number:

  ECX2-LMV-3CM-156.250-TR

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  SMD, 6 PIN

• Manufacturer:

  ECS International Inc

• YTEOL:

  6

• Additional Feature:

  ENABLE/DISABLE FUNCTION; COMPLEMENTARY OUTPUT; DIFFERENTIAL OUTPUT

• Fall Time-Max:

  0.3 ns

• Frequency Adjustment-Mechanical:

  NO

• Frequency Stability:

  25%

• JESD-609 Code:

  e4

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  6

• Operating Frequency-Nom:

  156.25 MHz

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -20 °C

• Oscillator Type:

  LVDS

• Output Load:

  100 OHM

• Package Equivalence Code:

  LCC6,.1X.13,75/47

• Physical Dimension:

  3.2mm x 2.5mm x 0.9mm

• Rise Time-Max:

  0.3 ns

• Supply Current-Max:

  24 mA

• Supply Voltage-Max:

  3.63 V

• Supply Voltage-Min:

  2.375 V

• Surface Mount:

  YES

• Symmetry-Max:

  45/55 %

• Terminal Finish:

  Gold (Au)
