EEETK1K331AM - Panasonic

EEETK1K331AM Details

• Manufacturer Part Number:

  EEETK1K331AM

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  CHIP

• Reach Compliance Code:

  Compliant

• Country Of Origin:

  Japan, Malaysia

• ECCN Code:

  EAR99

• HTS Code:

  8532.22.00.20

• Manufacturer:

  Panasonic Electronic Components

• YTEOL:

  7

• Additional Feature:

  ESR is MEASURED AT 100KHZ,

• Capacitance:

  330 µF

• Capacitor Type:

  ALUMINUM ELECTROLYTIC CAPACITOR

• Diameter:

  18 mm

• Dielectric Material:

  ALUMINUM (WET)

• ESR:

  280 mΩ

• Height:

  16.5 mm

• Leakage Current:

  0.264 mA

• Length:

  19 mm

• Mounting Feature:

  SURFACE MOUNT

• Negative Tolerance:

  20%

• Number of Terminals:

  2

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Package Shape:

  CYLINDRICAL PACKAGE

• Package Style:

  SMT

• Packing Method:

  TR, Embossed, 13 Inch

• Polarity:

  POLARIZED

• Positive Tolerance:

  20%

• Rated (DC) Voltage (URdc):

  80 V

• Reference Standard:

  AEC-Q200

• Ripple Current:

  300 mA

• Size Code:

  7575

• Surface Mount:

  YES

• Tan Delta:

  0.12

• Terminal Shape:

  FLAT

• Width:

  19 mm
