EEFCS1C220R - Panasonic

EEFCS1C220R Details

• Manufacturer Part Number:

  EEFCS1C220R

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Not Recommended

• Package Description:

  CHIP

• Reach Compliance Code:

  Compliant

• Country Of Origin:

  Japan

• ECCN Code:

  EAR99

• Factory Lead Time:

  40 Weeks

• Manufacturer:

  Panasonic Electronic Components

• YTEOL:

  3

• Additional Feature:

  ESR AND RIPPLE CURRENT IS MEASURED AT 100KHZ

• Capacitance:

  22 µF

• Capacitor Type:

  ALUMINUM ELECTROLYTIC CAPACITOR

• Dielectric Material:

  ALUMINUM (SOLID POLYMER)

• ESR:

  40 mΩ

• Height:

  1.1 mm

• Leakage Current:

  0.1056 mA

• Length:

  7.3 mm

• Mounting Feature:

  SURFACE MOUNT

• Negative Tolerance:

  20%

• Number of Terminals:

  2

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -55 °C

• Package Style:

  SMT

• Packing Method:

  TR, EMBOSSED, 7/13 INCH

• Polarity:

  POLARIZED

• Positive Tolerance:

  20%

• Rated (DC) Voltage (URdc):

  16 V

• Ripple Current:

  1600 mA

• Size Code:

  2917

• Surface Mount:

  YES

• Tan Delta:

  0.06

• Terminal Shape:

  WRAPAROUND

• Width:

  4.3 mm
