EEHZA1E221P - Panasonic

EEHZA1E221P Details

• Manufacturer Part Number:

  EEHZA1E221P

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  CHIP

• Reach Compliance Code:

  Compliant

• Country Of Origin:

  Japan

• ECCN Code:

  EAR99

• HTS Code:

  8532.22.00.20

• Factory Lead Time:

  14 Weeks

• Manufacturer:

  Panasonic Electronic Components

• YTEOL:

  9

• Additional Feature:

  ESR IS MEASURED AT 100 KHZ

• Capacitance:

  220 µF

• Capacitor Type:

  ALUMINUM ELECTROLYTIC CAPACITOR

• Diameter:

  8 mm

• Dielectric Material:

  ALUMINUM (SOLID POLYMER)

• ESR:

  27 mΩ

• Height:

  10.2 mm

• Leakage Current:

  0.055 mA

• Length:

  8.3 mm

• Mounting Feature:

  SURFACE MOUNT

• Negative Tolerance:

  20%

• Number of Terminals:

  2

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -55 °C

• Package Shape:

  CYLINDRICAL PACKAGE

• Package Style:

  SMT

• Packing Method:

  TR, EMBOSSED, 15 INCH

• Polarity:

  POLARIZED

• Positive Tolerance:

  20%

• Rated (DC) Voltage (URdc):

  25 V

• Reference Standard:

  AEC-Q200

• Ripple Current:

  345 mA

• Size Code:

  3333

• Surface Mount:

  YES

• Tan Delta:

  0.14

• Terminal Shape:

  FLAT

• Width:

  8.3 mm
