The recommended land pattern for EEHZA1J100V is a rectangular pad with a size of 2.5mm x 1.5mm, with a 0.5mm radius corner and a 0.3mm solder mask clearance.
Yes, EEHZA1J100V is rated for operation up to 125°C, making it suitable for high-temperature applications. However, it's essential to ensure that the component is properly derated and that the operating conditions do not exceed the maximum ratings.
The ESR (Equivalent Series Resistance) of EEHZA1J100V is 0.18Ω, which is relatively low. This low ESR helps to reduce energy losses and improve the overall efficiency of the circuit. However, it's essential to consider the ESR when designing the circuit to ensure that it meets the required performance specifications.
Yes, EEHZA1J100V is compatible with lead-free soldering. Panasonic Electronic Components ensures that their components meet the requirements of the RoHS (Restriction of Hazardous Substances) directive, which prohibits the use of lead and other hazardous substances in electronic components.
The recommended storage condition for EEHZA1J100V is in a dry, cool place with a temperature range of 5°C to 30°C and a relative humidity of 60% or less. It's essential to store the components in their original packaging or in a similar environment to prevent damage or degradation.
