Panasonic recommends a soldering temperature profile with a peak temperature of 260°C (500°F) for a maximum of 10 seconds, and a preheating temperature of 150°C (302°F) to 180°C (356°F) for 60 seconds to 120 seconds.
Yes, the EEHZU1J101V is designed to withstand high vibrations and is suitable for use in applications with vibration levels up to 10G (98m/s²). However, it's recommended to consult with Panasonic or a qualified engineer to ensure the capacitor meets the specific vibration requirements of your application.
The EEHZU1J101V is designed to be resistant to moisture and humidity, with a moisture sensitivity level of MSL 2A. It can withstand a maximum of 60% relative humidity at 40°C (104°F) for 96 hours. However, it's recommended to follow proper storage and handling procedures to prevent moisture absorption.
The ESR of the EEHZU1J101V is not explicitly stated in the datasheet, but it can be estimated to be around 0.1 ohms to 0.5 ohms at 100 kHz, based on similar capacitors from Panasonic. However, it's recommended to consult with Panasonic or a qualified engineer for a more accurate ESR value.
The EEHZU1J101V is rated for operation up to 105°C (221°F), but its capacitance and impedance characteristics may degrade at higher temperatures. It's recommended to consult with Panasonic or a qualified engineer to ensure the capacitor meets the specific temperature requirements of your application.
