ELUMOATHQ7C22 - LITTELFUSE

ELUMOATHQ7C22 Details

• Manufacturer Part Number:

  ELUMOATHQ7C22

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.70.00

• Manufacturer:

  Littelfuse Inc

• Actuator Color:

  BLACK

• Actuator Length:

  0.3 inch

• Actuator Material:

  GLASS FILLED NYLON

• Actuator Travel:

  5.08 mm

• Actuator Type:

  PUSHBUTTON

• Additional Feature:

  ROHS BLUE LED ILLUMINATION

• Body Breadth:

  11.43 mm

• Body Height:

  5.16 mm

• Body Length or Diameter:

  20.58 mm

• Bushing Diameter:

  0.1 inch

• Bushing Length:

  0.1 inch

• Center Contact Material:

  COPPER ALLOY

• Center Contact Plating:

  GOLD OVER SILVER

• Contact Current(DC)-Max:

  0.25 A

• Contact (DC) Max Rating R Load:

  0.25A@50VDC

• Contact Resistance:

  0.05 mΩ

• Contact Voltage(DC)-Max:

  50 V

• Dielectric Withstand Volts:

  250VAC V

• Electrical Life:

  30000 Cycle(s)

• End Contact Material:

  STAINLESS STEEL

• End Contact Plating:

  GOLD OVER SILVER

• Housing Material:

  STAINLESS STEEL

• Illumination:

  BLUE LED

• Insulation Resistance:

  1000000000 Ω

• Insulator Material:

  GLASS FILLED LCP

• Mounting Feature:

  THROUGH HOLE-RIGHT ANGLE

• Operating Force-Max:

  2.5 N

• Operating Temperature-Max:

  80 °C

• Operating Temperature-Min:

  -40 °C

• Packing Method:

  TRAY

• Surface Mount:

  NO

• Switch Action:

  MOMENTARY

• Switch Function:

  SPDT

• Switch Type:

  PUSHBUTTON SWITCH

• Terminal Finish:

  Gold (Au) - with Nickel (Ni) barrier

• Terminal Length:

  0.068 inch

• Terminal Material:

  STAINLESS STEEL

• Termination Type:

  SOLDER
