EMC2101-ACZT-TR - Microchip

Description: Board Mount Temperature Sensors Sngl Fan Contrllr

Download EMC2101-ACZT-TR Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
EMC2101-ACZT-TR - Microchip PCB footprint - Small Outline Packages - Small Outline Packages - EMC2101-ACZT-TR
click to zoom
3D Models
EMC2101-ACZT-TR - Microchip  - 3D model - Small Outline Packages - EMC2101-ACZT-TR
click to zoom

EMC2101-ACZT-TR Details

  • Manufacturer Part Number:

    EMC2101-ACZT-TR

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Package Description:

    4.90 X 3.90 MM, 1.27 MM PITCH, ROHS COMPLIANT, MS-012/AA, SOIC-8

  • Manufacturer:

    Microchip Technology Inc

  • YTEOL:

    0

  • Accuracy-Max (Cel):

    2 Cel

  • Additional Feature:

    HYSTERESIS 500MV

  • Body Breadth:

    3.9 mm

  • Body Height:

    1.55 mm

  • Body Length or Diameter:

    4.9 mm

  • JESD-609 Code:

    e3

  • Mounting Feature:

    SURFACE MOUNT

  • Number of Bits:

    11

  • Number of Terminals:

    8

  • Operating Current-Max:

    1 mA

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -40 °C

  • Output Interface Type:

    2-WIRE INTERFACE

  • Package Shape/Style:

    RECTANGULAR

  • Sensors/Transducers Type:

    TEMPERATURE SENSOR,SWITCH/DIGITAL OUTPUT,SERIAL

  • Supply Voltage-Max:

    3.6 V

  • Supply Voltage-Min:

    3 V

  • Surface Mount:

    YES

  • Terminal Finish:

    Matte Tin (Sn)

  • Termination Type:

    SOLDER

EMC2101-ACZT-TR Frequently Asked Questions (FAQs)

  • A 4-layer PCB with a solid ground plane and thermal vias is recommended for optimal thermal performance. The thermal pad should be connected to a large copper area on the PCB to dissipate heat efficiently.
  • Ensure that the device is operated within the recommended voltage and current limits, and that the PCB is designed to minimize thermal gradients. Also, consider using a thermal interface material to improve heat transfer between the device and the heat sink.
  • Use a common-mode choke and capacitors to filter out electromagnetic interference (EMI). Shielding can be achieved using a metal enclosure or a shielded cable. Ensure that the PCB layout is designed to minimize radiation and susceptibility to EMI.
  • Check the thermal monitoring output pin (TMON) for proper connection and routing. Verify that the thermal monitoring function is enabled and configured correctly. Use an oscilloscope to monitor the TMON pin and verify that it is within the expected range.
  • Ensure that the power supplies are sequenced correctly to prevent damage to the device. The recommended power-up sequence is VCC, then VDD. The supply voltage should be within the recommended range of 3.0V to 3.6V.
