EML30US15-E - XP POWER

EML30US15-E Details

• Manufacturer Part Number:

  EML30US15-E

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  PACKAGE-4

• ECCN Code:

  EAR99

• Date Of Intro:

  2019-06-11

• Manufacturer:

  XP Power

• YTEOL:

  7

• Additional Feature:

  120-370 VDC ADDITIONAL INPUT IS AVAILABLE

• Analog IC - Other Type:

  AC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  AAMI, ANSI, CB, CE, CSA, EN, ES, IEC, TUV, UKCA,UL

• Efficiency (Main Output):

  88%

• Input Voltage-Max:

  264 V

• Input Voltage-Min:

  85 V

• Input Voltage-Nom:

  115 V

• JESD-30 Code:

  R-XDMA-P4

• Length:

  78.7 mm

• Line Regulation-Max:

  0.5%

• Load Regulation-Max:

  1%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  4

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -20 °C

• Output Current-Max:

  2.6 A

• Output Voltage-Max:

  15.75 V

• Output Voltage-Min:

  14.25 V

• Output Voltage-Nom:

  15 V

• Package Code:

  DMA

• Package Equivalence Code:

  MODULE,4LEAD,2.8

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  OVER LOAD, OVER VOLTAGE, SHORT CIRCUIT

• Ripple Voltage (Main Out):

  0.042 Vrms

• Screening Level:

  EN/ES/IEC 60601-1, TWO MOPP

• Seated Height-Max:

  28.4 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Total Power Output-Max:

  30 W

• Trim/Adjustable Output:

  YES

• Warm-up Time:

  2.014 s

• Width:

  38.1 mm
