EP2C70F672I8N - Intel

EP2C70F672I8N Details

• Manufacturer Part Number:

  EP2C70F672I8N

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Transferred

• Package Description:

  LEAD FREE, FBGA-672

• Country Of Origin:

  Mainland China, Malaysia, Taiwan, USA, Vietnam

• HTS Code:

  8542.31.00.60

• Manufacturer:

  Intel Corporation

• YTEOL:

  10

• Additional Feature:

  ALSO REQUIRES 3.3 SUPPLY

• Clock Frequency-Max:

  402.5 MHz

• JESD-30 Code:

  S-PBGA-B672

• JESD-609 Code:

  e1

• Length:

  27 mm

• Moisture Sensitivity Level:

  3

• Number of CLBs:

  4276

• Number of Inputs:

  422

• Number of Logic Cells:

  68416

• Number of Outputs:

  406

• Number of Terminals:

  672

• Operating Temperature-Max:

  100 °C

• Operating Temperature-Min:

  -40 °C

• Organization:

  4276 CLBS

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  BGA

• Package Equivalence Code:

  BGA672,26X26,40

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY

• Programmable Logic Type:

  FIELD PROGRAMMABLE GATE ARRAY

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  2.6 mm

• Supply Voltage-Max:

  1.25 V

• Supply Voltage-Min:

  1.15 V

• Supply Voltage-Nom:

  1.2 V

• Surface Mount:

  YES

• Technology:

  CMOS, 90 nm

• Terminal Finish:

  Tin/Silver/Copper (Sn/Ag/Cu)

• Terminal Form:

  BALL

• Terminal Pitch:

  1 mm

• Terminal Position:

  BOTTOM

• Width:

  27 mm
