EPF10K100ARC240-3 - Intel

EPF10K100ARC240-3 Details

• Manufacturer Part Number:

  EPF10K100ARC240-3

• Part Life Cycle Code:

  Obsolete

• Package Description:

  RQFP-240

• HTS Code:

  8542.31.00.55

• Manufacturer:

  Intel Corporation

• YTEOL:

  0

• Clock Frequency-Max:

  322.58 MHz

• JESD-30 Code:

  S-PQFP-G240

• JESD-609 Code:

  e0

• Length:

  32 mm

• Moisture Sensitivity Level:

  3

• Number of Dedicated Inputs:

  4

• Number of I/O Lines:

  185

• Number of Inputs:

  189

• Number of Logic Cells:

  4992

• Number of Outputs:

  185

• Number of Terminals:

  240

• Operating Temperature-Max:

  70 °C

• Organization:

  4 DEDICATED INPUTS, 181 I/O

• Output Function:

  REGISTERED

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  HFQFP

• Package Equivalence Code:

  HQFP240,1.37SQ,20

• Package Shape:

  SQUARE

• Package Style:

  FLATPACK, HEAT SINK/SLUG, FINE PITCH

• Programmable Logic Type:

  LOADABLE PLD

• Propagation Delay:

  0.8 ns

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  4.1 mm

• Supply Voltage-Max:

  3.6 V

• Supply Voltage-Min:

  3 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  COMMERCIAL

• Terminal Finish:

  TIN LEAD

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  QUAD

• Width:

  32 mm
