ERA-8SM - Mini-Circuits

ERA-8SM Details

• Manufacturer Part Number:

  ERA-8SM

• Part Life Cycle Code:

  Obsolete

• Package Description:

  PLASTIC, CASE WW107, MICRO-X, 4 PIN

• Manufacturer:

  Mini-Circuits

• YTEOL:

  0

• Additional Feature:

  LOW NOISE

• Characteristic Impedance:

  50 Ω

• Construction:

  COMPONENT

• Gain:

  22.9 dB

• Input Power-Max (CW):

  13 dBm

• JESD-609 Code:

  e0

• Mounting Feature:

  SURFACE MOUNT

• Number of Functions:

  1

• Number of Terminals:

  4

• Operating Frequency-Max:

  2000 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -45 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Equivalence Code:

  SL,4GW-LD,.085CIR

• Power Supplies:

  3.7 V

• RF/Microwave Device Type:

  WIDE BAND LOW POWER

• Surface Mount:

  YES

• Terminal Finish:

  Tin/Lead (Sn/Pb)

• VSWR-Max:

  2.2
