ES9311Q - ESS Technology

Description: Digital to Analog Converters - DAC Sabre Ultra low noise reference generator

Download ES9311Q Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
ES9311Q - ESS Technology PCB footprint - Quad Flat No-Lead - Quad Flat No-Lead - QFN-30 Pin
click to zoom
3D Models
ES9311Q - ESS Technology  - 3D model - Quad Flat No-Lead - QFN-30 Pin
click to zoom

ES9311Q Details

  • Manufacturer Part Number:

    ES9311Q

  • Part Life Cycle Code:

    Contact Manufacturer

  • Package Description:

    QFN-30

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Manufacturer:

    Ess Technology Inc

  • Adjustability:

    FIXED/ADJUSTABLE

  • Dropout Voltage1-Nom:

    0.05 V

  • Input Voltage Absolute-Max:

    6 V

  • JESD-30 Code:

    R-XQCC-N30

  • Length:

    5 mm

  • Number of Functions:

    1

  • Number of Outputs:

    2

  • Number of Terminals:

    30

  • Operating Temperature TJ-Max:

    125 °C

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -25 °C

  • Output Current1-Max:

    150 A

  • Output Current2-Max:

    150 A

  • Output Voltage1-Max:

    5.3 V

  • Output Voltage1-Min:

    2.5 V

  • Output Voltage1-Nom:

    3.3 V

  • Output Voltage2-Max:

    5.3 V

  • Output Voltage2-Min:

    2.5 V

  • Output Voltage2-Nom:

    3.3 V

  • Package Body Material:

    UNSPECIFIED

  • Package Code:

    HVQCCN

  • Package Equivalence Code:

    LCC30,.12X20,16

  • Package Shape:

    RECTANGULAR

  • Package Style:

    CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

  • Regulator Type:

    FIXED/ADJUSTABLE POSITIVE MULTIPLE OUTPUT LDO REGULATOR

  • Seated Height-Max:

    0.8 mm

  • Surface Mount:

    YES

  • Terminal Form:

    NO LEAD

  • Terminal Pitch:

    0.4 mm

  • Terminal Position:

    QUAD

  • Voltage Tolerance-Max:

    0.91%

  • Width:

    3 mm
