ESD5V3U4U-HDMI - Infineon

ESD5V3U4U-HDMI Details

• Manufacturer Part Number:

  ESD5V3U4U-HDMI

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  DFN

• Package Description:

  ROHS COMPLIANT, TSLP-9-1, 9 PIN

• Pin Count:

  9

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.50

• Manufacturer:

  Infineon Technologies AG

• YTEOL:

  0

• Breakdown Voltage-Min:

  6 V

• Case Connection:

  ANODE

• Clamping Voltage-Max:

  28 V

• Configuration:

  COMMON ANODE, 4 ELEMENTS, 4 CHANNEL

• Diode Element Material:

  SILICON

• Diode Type:

  TRANS VOLTAGE SUPPRESSOR DIODE

• JESD-30 Code:

  R-XBCC-N9

• Moisture Sensitivity Level:

  1

• Number of Elements:

  4

• Number of Terminals:

  9

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  UNSPECIFIED

• Package Shape:

  RECTANGULAR

• Package Style:

  CHIP CARRIER

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Polarity:

  UNIDIRECTIONAL

• Qualification Status:

  Not Qualified

• Reference Standard:

  IEC-61000-4-2, 4-4, 4-5

• Rep Pk Reverse Voltage-Max:

  5.3 V

• Reverse Current-Max:

  0.05 µA

• Reverse Test Voltage:

  5.3 V

• Surface Mount:

  YES

• Technology:

  AVALANCHE

• Terminal Form:

  NO LEAD

• Terminal Position:

  BOTTOM

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED
