ESD7104MUTAG - onsemi

Description: ON Semiconductor ESD7104MUTAG, Quint Uni-Directional ESD Protection Array, 10-Pin U-DFN2510

Download ESD7104MUTAG Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
ESD7104MUTAG - onsemi PCB footprint - Other - Other - UDFN10 2.5x1, 0.5P CASE 517BB−01 ISSUE O
click to zoom
3D Models
ESD7104MUTAG - onsemi  - 3D model - Other - UDFN10 2.5x1, 0.5P CASE 517BB−01 ISSUE O
click to zoom

ESD7104MUTAG Details

  • Manufacturer Part Number:

    ESD7104MUTAG

  • Brand Name:

    onsemi

  • Pbfree Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    UDFN10, 2.5x1, 0.5P

  • Package Description:

    UDFN-10

  • Pin Count:

    10

  • Manufacturer Package Code:

    517BB

  • Reach Compliance Code:

    compliant

  • Country Of Origin:

    Malaysia

  • ECCN Code:

    EAR99

  • HTS Code:

    8541.10.00.50

  • Factory Lead Time:

    4 Weeks

  • Manufacturer:

    onsemi

  • Risk Rank:

    0.88

  • YTEOL:

    6.48

  • Additional Feature:

    ULTRA LOW CAPACITANCE

  • Breakdown Voltage-Min:

    5.5 V

  • Clamping Voltage-Max:

    19.5 V

  • Configuration:

    COMPLEX

  • Diode Element Material:

    SILICON

  • Diode Type:

    TRANS VOLTAGE SUPPRESSOR DIODE

  • JESD-30 Code:

    R-XDSO-N10

  • JESD-609 Code:

    e3

  • Moisture Sensitivity Level:

    1

  • Number of Elements:

    4

  • Number of Terminals:

    10

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -55 °C

  • Package Body Material:

    UNSPECIFIED

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE

  • Peak Reflow Temperature (Cel):

    260

  • Polarity:

    UNIDIRECTIONAL

  • Reference Standard:

    IEC-61000-4-2

  • Rep Pk Reverse Voltage-Max:

    5 V

  • Reverse Current-Max:

    1 µA

  • Reverse Test Voltage:

    5 V

  • Surface Mount:

    YES

  • Technology:

    AVALANCHE

  • Terminal Finish:

    MATTE TIN

  • Terminal Form:

    NO LEAD

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    30
