ESDA25B1RL - STMicroelectronics

ESDA25B1RL Details

• Manufacturer Part Number:

  ESDA25B1RL

• Brand Name:

  STMicroelectronics

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  SOD

• Package Description:

  PLASTIC, SOP-8

• Pin Count:

  8

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.50

• Factory Lead Time:

  15 Weeks

• Manufacturer:

  STMicroelectronics

• YTEOL:

  0

• Breakdown Voltage-Max:

  30 V

• Breakdown Voltage-Min:

  25 V

• Breakdown Voltage-Nom:

  27.5 V

• Configuration:

  COMPLEX, 6 CHANNEL

• Diode Capacitance-Min:

  15 pF

• Diode Element Material:

  SILICON

• Diode Type:

  TRANS VOLTAGE SUPPRESSOR DIODE

• JESD-30 Code:

  R-PDSO-G8

• JESD-609 Code:

  e4

• Moisture Sensitivity Level:

  1

• Non-rep Peak Rev Power Dis-Max:

  150 W

• Number of Elements:

  8

• Number of Terminals:

  8

• Operating Temperature-Max:

  125 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  260

• Polarity:

  BIDIRECTIONAL

• Qualification Status:

  Not Qualified

• Reference Standard:

  IEC-1000-4-2, MIL-STD-883C

• Rep Pk Reverse Voltage-Max:

  24 V

• Reverse Current-Max:

  2 µA

• Reverse Test Voltage:

  24 V

• Surface Mount:

  YES

• Technology:

  AVALANCHE

• Terminal Finish:

  Nickel/Palladium/Gold (Ni/Pd/Au)

• Terminal Form:

  GULL WING

• Terminal Position:

  DUAL
