ESDULC3V3PRB-TP - MCC

ESDULC3V3PRB-TP Details

• Manufacturer Part Number:

  ESDULC3V3PRB-TP

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  DFN5515-18, 18 PIN

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.50

• Manufacturer:

  Micro Commercial Components

• YTEOL:

  6

• Breakdown Voltage-Min:

  3.5 V

• Clamping Voltage-Max:

  15 V

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON

• Diode Type:

  TRANS VOLTAGE SUPPRESSOR DIODE

• JESD-30 Code:

  R-PDSO-N18

• Moisture Sensitivity Level:

  1

• Non-rep Peak Rev Power Dis-Max:

  45 W

• Number of Elements:

  1

• Number of Terminals:

  18

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  260

• Polarity:

  UNIDIRECTIONAL

• Reference Standard:

  IEC-61000-4-2, 4-5

• Rep Pk Reverse Voltage-Max:

  3.3 V

• Reverse Current-Max:

  0.2 µA

• Reverse Test Voltage:

  3.3 V

• Surface Mount:

  YES

• Technology:

  AVALANCHE

• Terminal Form:

  NO LEAD

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  40
