ETQP8MR33JFA - Panasonic

ETQP8MR33JFA Details

• Manufacturer Part Number:

  ETQP8MR33JFA

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  CHIP

• Country Of Origin:

  Japan

• ECCN Code:

  EAR99

• HTS Code:

  8504.50.80.00

• Manufacturer:

  Panasonic Electronic Components

• YTEOL:

  8

• Case/Size Code:

  5250

• Construction:

  Rectangular

• Core Material:

  METAL COMPOSITE

• DC Resistance:

  0.00077 Ω

• Inductance-Nom (L):

  0.33 µH

• Inductor Application:

  POWER INDUCTOR

• Inductor Type:

  GENERAL PURPOSE INDUCTOR

• Number of Functions:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  160 °C

• Operating Temperature-Min:

  -40 °C

• Package Height:

  8 mm

• Package Length:

  13.2 mm

• Package Style:

  SMT

• Package Width:

  12.6 mm

• Packing Method:

  TR, EMBOSSED, 13 INCH

• Rated Current-Max:

  53.5 A

• Reference Standard:

  AEC-Q200

• Shape/Size Description:

  RECTANGULAR PACKAGE

• Shielded:

  YES

• Special Feature:

  DC RESISTANCE IS MEASURED AT: 10%

• Surface Mount:

  YES

• Terminal Placement:

  DUAL ENDED

• Terminal Shape:

  WRAPAROUND

• Test Frequency:

  0.1 MHz

• Tolerance:

  20%
