EVQPLDA15 - Panasonic

Description: Switch Tactile N.O. SPST Round Button J-Bend 0.02A 15VDC 1N SMD Embossed Tape - Tape and Reel

Download EVQPLDA15 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
EVQPLDA15 - Panasonic PCB footprint - Other - Other - EVQPLDA15-2
click to zoom
3D Models
EVQPLDA15 - Panasonic  - 3D model - Other - EVQPLDA15-2
click to zoom

EVQPLDA15 Details

  • Manufacturer Part Number:

    EVQPLDA15

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Country Of Origin:

    Japan, Mainland China

  • ECCN Code:

    EAR99

  • HTS Code:

    8536.50.90.40

  • Factory Lead Time:

    29 Weeks, 2 Days

  • Manufacturer:

    Panasonic Electronic Components

  • YTEOL:

    8

  • Body Breadth:

    4.9 mm

  • Body Height:

    0.8 mm

  • Body Length or Diameter:

    4.9 mm

  • Circuit Configuration:

    1X1

  • Contact Bounce Time-Max:

    8 ms

  • Contact Current(DC)-Max:

    0.02 A

  • Contact (DC) Max Rating R Load:

    .02A@15VDC

  • Contact Voltage(DC)-Max:

    15 V

  • Electrical Life:

    500000 Cycle(s)

  • JESD-609 Code:

    e4

  • Mounting Feature:

    SURFACE MOUNT-STRAIGHT

  • Number of Switches:

    1

  • Operating Force-Max:

    1.5 N

  • Operating Temperature-Max:

    70 °C

  • Operating Temperature-Min:

    -20 °C

  • Packing Method:

    BOX; TAPE AND REEL

  • Surface Mount:

    NO

  • Switch Action:

    MOMENTARY

  • Switch Function:

    SPST

  • Switch Type:

    KEYPAD SWITCH

  • Terminal Finish:

    GOLD/SILVER

  • Termination Type:

    SOLDER
