EX10E-280S - Hirose

EX10E-280S Details

• Manufacturer Part Number:

  EX10E-280S

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.30

• Manufacturer:

  Hirose Electric Co Ltd

• YTEOL:

  9

• Board Mounting Option:

  PEG

• Body Breadth:

  0.394 inch

• Body Depth:

  0.827 inch

• Body Length:

  3.126 inch

• Body/Shell Style:

  RECEPTACLE

• Connector Type:

  BOARD CONNECTOR

• Contact Gender:

  FEMALE

• Contact Pattern:

  RECTANGULAR

• Contact Resistance:

  125 mΩ

• Contact Style:

  SQ PIN-SKT

• Dielectric Withstanding Voltage:

  400VAC V

• Durability:

  10000 Cycles

• Filter Feature:

  NO

• Insertion Force-Max:

  40 N

• Insulation Resistance:

  250000000 Ω

• Insulator Color:

  NATURAL

• Insulator Material:

  LIQUID CRYSTAL POLYMER

• Mating Contact Pitch:

  0.031 inch

• Mating Information:

  MULTIPLE MATING PARTS AVAILABLE

• Mixed Contacts:

  NO

• Mounting Option 1:

  M3X0.5

• Mounting Option 2:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Number Of PCB Rows:

  8

• Number of Rows Loaded:

  4

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -25 °C

• Option:

  GENERAL PURPOSE

• PCB Contact Pattern:

  STAGGERED

• PCB Contact Row Spacing:

  1.35 mm

• Plating Thickness:

  19.69u inch

• Rated Current (Signal):

  0.5 A

• Reference Standard:

  UL

• Terminal Length:

  0.085 inch

• Terminal Pitch:

  1.6 mm

• Termination Type:

  SOLDER

• Total Number of Contacts:

  280

• UL Flammability Code:

  94V-0

• Withdrawl Force-Min:

  40 N
