EZ1582CM-1.5T - SEMTECH

EZ1582CM-1.5T Details

• Manufacturer Part Number:

  EZ1582CM-1.5T

• Pbfree Code:

  No

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  D2PAK

• Package Description:

  TO-263, 5 PIN

• Pin Count:

  4

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Semtech Corporation

• YTEOL:

  0

• Dropout Voltage1-Max:

  0.6 V

• Input Voltage-Max:

  5.5 V

• Input Voltage-Min:

  1.75 V

• JESD-30 Code:

  R-PSSO-G5

• JESD-609 Code:

  e0

• Length:

  9.97 mm

• Number of Functions:

  1

• Number of Terminals:

  5

• Operating Temperature TJ-Max:

  125 °C

• Output Current1-Max:

  3 A

• Output Voltage1-Nom:

  1.5 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  TO-263

• Package Equivalence Code:

  SMSIP5H,.6,67TB

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Qualification Status:

  Not Qualified

• Regulator Type:

  FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR

• Seated Height-Max:

  4.8 mm

• Surface Mount:

  YES

• Terminal Finish:

  TIN LEAD

• Terminal Form:

  GULL WING

• Terminal Pitch:

  1.7 mm

• Terminal Position:

  SINGLE

• Width:

  8.955 mm
