Texas Instruments provides a recommended PCB layout guide in their application note SLUA365, which includes guidelines for thermal pad connections, copper pours, and via placement to minimize thermal resistance and ensure optimal heat dissipation.
The F280025PTSR has a complex clocking system. Refer to the 'Clocking' section in the datasheet and the 'TMS320F28002x Piccolo Microcontrollers Clocking and Systems' application note (SLAU144) for detailed information on clock source selection, PLL configuration, and clock domain crossing.
TI provides guidelines for EMI and EMC in their application note SLAA513, which covers topics such as PCB layout, component selection, and shielding techniques to minimize electromagnetic radiation and ensure compliance with regulatory standards.
TI recommends using their Code Composer Studio (CCS) integrated development environment (IDE) for flash programming. CCS provides a built-in flash programmer and supports various programming methods, including JTAG, SPI, and BSL (Bootloader). Refer to the CCS user guide and the F280025PTSR datasheet for more information.
The POR threshold is typically around 1.8V, and the BOR threshold is around 1.9V. However, these values can vary depending on the specific device and operating conditions. Refer to the datasheet and the 'Power-On Reset and Brown-Out Reset' section in the 'TMS320F28002x Piccolo Microcontrollers System Integration' application note (SLAU145) for more information.
