FAN48632BUC33X - onsemi

FAN48632BUC33X Details

• Manufacturer Part Number:

  FAN48632BUC33X

• Brand Name:

  onsemi

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  WLCSP-16

• Manufacturer Package Code:

  567SY

• Country Of Origin:

  Taiwan

• HTS Code:

  8542.39.00.01

• Manufacturer:

  onsemi

• YTEOL:

  0

• Analog IC - Other Type:

  ANALOG CIRCUIT

• Control Mode:

  CURRENT-MODE

• JESD-30 Code:

  S-PBGA-B16

• JESD-609 Code:

  e1

• Length:

  1.78 mm

• Moisture Sensitivity Level:

  1

• Number of Functions:

  1

• Number of Terminals:

  16

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  1.5 A

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  VFBGA

• Package Equivalence Code:

  BGA16,4X4,16

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY, VERY THIN PROFILE, FINE PITCH

• Peak Reflow Temperature (Cel):

  260

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  0.625 mm

• Supply Voltage-Max (Vsup):

  5.5 V

• Supply Voltage-Min (Vsup):

  2.35 V

• Supply Voltage-Nom (Vsup):

  3 V

• Surface Mount:

  YES

• Switching Frequency-Max:

  3000 kHz

• Temperature Grade:

  INDUSTRIAL

• Terminal Finish:

  TIN SILVER COPPER

• Terminal Form:

  BALL

• Terminal Pitch:

  0.4 mm

• Terminal Position:

  BOTTOM

• Time@Peak Reflow Temperature-Max (s):

  30

• Width:

  1.78 mm
