FC-L01DV1 - Mornsun Power

FC-L01DV1 Frequently Asked Questions (FAQs)

• What is the recommended PCB layout for optimal thermal performance?
  MORNSUN recommends a PCB layout with a large copper area connected to the GND pin to dissipate heat effectively. A minimum of 1 oz copper thickness is recommended.
• Can I use the FC-L01DV1 in a high-vibration environment?
  Yes, the FC-L01DV1 is designed to withstand vibrations up to 10G (10-2000Hz) and can be used in high-vibration environments. However, it's recommended to follow proper mounting and soldering procedures to ensure reliability.
• What is the maximum capacitance I can use on the output?
  MORNSUN recommends using output capacitors with a maximum capacitance of 47uF to ensure stability and prevent oscillation. Larger capacitance values may cause instability or affect the converter's performance.
• Can I use the FC-L01DV1 in a humid environment?
  The FC-L01DV1 is designed to operate in a relative humidity range of 20% to 80%. However, it's recommended to follow proper conformal coating and sealing procedures to ensure reliability in humid environments.
• What is the recommended input fuse rating?
  MORNSUN recommends using a fuse with a rating of 1A to 2A, depending on the input voltage and current requirements. The fuse should be able to handle the maximum input current and provide adequate protection against overcurrent conditions.
