FDA903S-6DY Frequently Asked Questions (FAQs)

• What is the recommended PCB layout for optimal performance?
  A 4-layer PCB with a solid ground plane and a separate power plane is recommended. Keep the analog and digital grounds separate and connect them at a single point. Use a 10uF capacitor between VCC and GND, and a 100nF capacitor between AVCC and AGND.
• How do I ensure electromagnetic compatibility (EMC) compliance?
  Use a metal shield around the device, and ensure that the PCB layout is designed to minimize radiation. Use a common-mode choke and a ferrite bead in the power supply lines to reduce electromagnetic interference (EMI).
• What is the recommended power-up sequence for the device?
  Power up the device in the following sequence: VCC, AVCC, and then the digital power supplies. Ensure that the power supplies are stable before applying the clock signal.
• How do I handle the device's thermal management?
  Use a heat sink with a thermal resistance of less than 10°C/W. Ensure good airflow around the device, and avoid blocking the airflow with components or obstacles.
• What is the recommended clock signal quality for the device?
  The clock signal should have a frequency of 12.288 MHz, with a duty cycle of 50% ± 5%. The clock signal should also have a rise and fall time of less than 5 ns.
