FDMS7570S - onsemi

Description: Obsolete - N-Channel PowerTrench SyncFET 25V, 49A, 2.9mΩ

Download FDMS7570S Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
FDMS7570S - onsemi PCB footprint - Other - Other - PQFN8 5X6, 1.27P CASE 483AE ISSUE A_2019OCT
click to zoom
3D Models
FDMS7570S - onsemi  - 3D model - Other - PQFN8 5X6, 1.27P CASE 483AE ISSUE A_2019OCT
click to zoom

FDMS7570S Details

  • Manufacturer Part Number:

    FDMS7570S

  • Brand Name:

    onsemi

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Part Package Code:

    PQFN-8

  • Package Description:

    ROHS COMPLIANT, POWER 56, 8 PIN

  • Manufacturer Package Code:

    483AE

  • ECCN Code:

    EAR99

  • Factory Lead Time:

    4 Weeks

  • Manufacturer:

    onsemi

  • YTEOL:

    0

  • Avalanche Energy Rating (Eas):

    144 mJ

  • Case Connection:

    DRAIN

  • Configuration:

    SINGLE WITH BUILT-IN DIODE
