The recommended land pattern for the FG28X7R1H104KNT00 can be found in the TDK Corporation's Capacitor Land Pattern Guidelines document, which provides detailed information on pad layout and spacing for optimal performance and reliability.
The FG28X7R1H104KNT00 is a high-frequency capacitor with a self-resonant frequency of around 1.5 GHz. It is suitable for high-frequency applications such as decoupling, filtering, and impedance matching. However, it's essential to consider the capacitor's impedance characteristics and parasitic effects at high frequencies to ensure optimal performance.
The FG28X7R1H104KNT00 is an industrial-grade capacitor, but it may not meet the specific requirements for automotive applications. TDK Corporation offers a range of automotive-grade capacitors that meet the AEC-Q200 standard, which is recommended for use in automotive systems.
The FG28X7R1H104KNT00 has a maximum operating temperature range of -55°C to +125°C, as specified in the datasheet. However, it's essential to consider the derating curves and temperature coefficients to ensure the capacitor operates within its specified parameters.
The FG28X7R1H104KNT00 is a surface-mount device (SMD) capacitor, which can be susceptible to vibration and mechanical stress. TDK Corporation recommends using capacitors with specialized vibration-resistant designs, such as their Vibration-Resistant Capacitor series, for high-vibration applications.
Trust Checks
This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
FG28X7R1H104KNT00 Overview
Use the download button to access the FG28X7R1H104KNT00 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like FG28X,
or try a keyword search, such as Ceramic Capacitors
