FL3840006 - Diodes Incorporated

Description: Crystals 38.400MHz 10pF 10ppm -30 to +85

Download FL3840006 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
FL3840006 - Diodes Incorporated PCB footprint - Other - Other - FL3840006-3
click to zoom
3D Models
FL3840006 - Diodes Incorporated  - 3D model - Other - FL3840006-3
click to zoom

FL3840006 Details

  • Manufacturer Part Number:

    FL3840006

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Country Of Origin:

    Taiwan

  • ECCN Code:

    EAR99

  • HTS Code:

    8541.60.00.60

  • Factory Lead Time:

    12 Weeks

  • Manufacturer:

    Diodes Incorporated

  • YTEOL:

    7

  • Additional Feature:

    AT-CUT; TR, 7 INCH

  • Aging:

    3 PPM/FIRST YEAR

  • Crystal/Resonator Type:

    PARALLEL - FUNDAMENTAL

  • Drive Level:

    100 µW

  • Frequency Stability:

    0.001%

  • Frequency Tolerance (MHz):

    10

  • JESD-609 Code:

    e4

  • Load Capacitance:

    10 pF

  • Mounting Feature:

    SURFACE MOUNT

  • Operating Frequency-Nom:

    38.4 MHz

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -30 °C

  • Physical Dimension:

    L3.2XB2.5XH0.65 (mm)/L0.126XB0.098XH0.026 (inch)

  • Series Resistance:

    40 Ω

  • Surface Mount:

    YES

  • Terminal Finish:

    GOLD OVER NICKEL
