FP35R12W2T4 - Infineon

FP35R12W2T4 Details

• Manufacturer Part Number:

  FP35R12W2T4

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  MODULE

• Pin Count:

  35

• Country Of Origin:

  Germany, Mainland China

• ECCN Code:

  EAR99

• Manufacturer:

  Infineon Technologies AG

• YTEOL:

  5

• Case Connection:

  ISOLATED

• Collector Current-Max (IC):

  54 A

• Collector-Emitter Voltage-Max:

  1200 V

• Configuration:

  COMPLEX

• Gate-Emitter Voltage-Max:

  20 V

• JESD-30 Code:

  R-XUFM-X23

• Number of Elements:

  7

• Number of Terminals:

  23

• Operating Temperature-Max:

  175 °C

• Package Body Material:

  UNSPECIFIED

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Polarity/Channel Type:

  N-CHANNEL

• Power Dissipation-Max (Abs):

  215 W

• Qualification Status:

  Not Qualified

• Surface Mount:

  NO

• Terminal Form:

  UNSPECIFIED

• Terminal Position:

  UPPER

• Transistor Application:

  POWER CONTROL

• Transistor Element Material:

  SILICON

• Turn-off Time-Nom (toff):

  510 ns

• Turn-on Time-Nom (ton):

  43 ns

• VCEsat-Max:

  2.25 V
