FPF2266UCX - onsemi

FPF2266UCX Details

• Manufacturer Part Number:

  FPF2266UCX

• Brand Name:

  onsemi

• Pbfree Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  WLCSP16 1.56x1.56x0.29, 0.40P

• Package Description:

  WLCSP-16

• Manufacturer Package Code:

  567UX

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Factory Lead Time:

  18 Weeks

• Manufacturer:

  onsemi

• YTEOL:

  7

• Additional Feature:

  CURRENT LIMIT:1.3A; THERMAL SHUTDOWN:135C

• Adjustable Threshold:

  NO

• Analog IC - Other Type:

  LOAD SWITCH

• JESD-30 Code:

  S-XBGA-B16

• Length:

  1.56 mm

• Number of Functions:

  1

• Number of Terminals:

  16

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  UNSPECIFIED

• Package Code:

  VFBGA

• Package Equivalence Code:

  BGA16,4X4,16

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY, VERY THIN PROFILE, FINE PITCH

• Seated Height-Max:

  0.528 mm

• Supply Voltage-Max (Vsup):

  24 V

• Supply Voltage-Min (Vsup):

  3.6 V

• Supply Voltage-Nom (Vsup):

  5 V

• Surface Mount:

  YES

• Terminal Form:

  BALL

• Terminal Pitch:

  0.4 mm

• Terminal Position:

  BOTTOM

• Width:

  1.56 mm
