FPF2498BUCX - onsemi

Description: Power Switch ICs - Power Distribution 28V OVP LOAD SWITCH

Download FPF2498BUCX Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
FPF2498BUCX - onsemi PCB footprint - BGA - BGA - WLCSP6 1.30x1.05x0.586 CASE 567RT ISSUE O
click to zoom
3D Models
FPF2498BUCX - onsemi  - 3D model - BGA - WLCSP6 1.30x1.05x0.586 CASE 567RT ISSUE O
click to zoom

FPF2498BUCX Details

  • Manufacturer Part Number:

    FPF2498BUCX

  • Brand Name:

    onsemi

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Package Description:

    WLCSP-6

  • Manufacturer Package Code:

    567RT

  • Country Of Origin:

    Taiwan

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Manufacturer:

    onsemi

  • YTEOL:

    0

  • Additional Feature:

    Trip Current:2A;Thermal Shutdown:150C

  • Adjustable Threshold:

    YES

  • Analog IC - Other Type:

    Load switch

  • JESD-30 Code:

    R-PBGA-B6

  • JESD-609 Code:

    e1

  • Length:

    1.3 mm

  • Moisture Sensitivity Level:

    1

  • Number of Channels:

    1

  • Number of Functions:

    1

  • Number of Terminals:

    6

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    VFBGA

  • Package Equivalence Code:

    BGA6,2X3,16

  • Package Shape:

    RECTANGULAR

  • Package Style:

    GRID ARRAY, VERY THIN PROFILE, FINE PITCH

  • Peak Reflow Temperature (Cel):

    260

  • Seated Height-Max:

    0.625 mm

  • Supply Voltage-Max (Vsup):

    12 V

  • Supply Voltage-Min (Vsup):

    3.5 V

  • Supply Voltage-Nom (Vsup):

    5 V

  • Surface Mount:

    YES

  • Terminal Finish:

    Tin/Silver/Copper (Sn/Ag/Cu)

  • Terminal Form:

    BALL

  • Terminal Pitch:

    0.4 mm

  • Terminal Position:

    BOTTOM

  • Threshold Voltage-Nom:

    +1.2V

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    1.05 mm

FPF2498BUCX Frequently Asked Questions (FAQs)

  • A 2-layer or 4-layer PCB with a solid ground plane and thermal vias is recommended. Keep the thermal pad connected to the ground plane to improve heat dissipation.
  • Ensure the input voltage is within the recommended range (2.7V to 5.5V) and the enable pin is properly biased (high or low) according to the application requirements.
  • The maximum current rating for the output pins is 100mA per pin. Exceeding this rating may cause damage to the device.
  • Follow the recommended power-up and power-down sequences outlined in the datasheet to prevent damage to the device and ensure proper operation.
  • Use ESD protection devices such as TVS diodes or ESD arrays on the input and output pins to prevent damage from electrostatic discharge.
