A good PCB layout for optimal thermal performance involves placing thermal vias under the FR104G package, using a solid ground plane, and keeping the thermal path as short as possible. It's also recommended to use a thermal pad on the bottom of the package.
To ensure reliable operation at high temperatures, it's essential to follow the recommended operating conditions, use a suitable thermal management system, and consider derating the device's power dissipation. Additionally, ensure that the PCB is designed to minimize thermal resistance and that the device is properly soldered.
The recommended soldering conditions for the FR104G are: peak temperature of 260°C, soldering time of 10 seconds, and a soldering temperature profile that follows the JEDEC J-STD-020 standard.
To handle the FR104G's ESD sensitivity, it's essential to follow proper ESD handling procedures, such as using an ESD wrist strap, ESD mat, or ESD bag. Additionally, ensure that the device is stored in a dry, ESD-safe environment, and avoid touching the device's pins or leads.
The recommended storage conditions for the FR104G are: temperature range of -40°C to 125°C, humidity of 60% or less, and storage in a dry, ESD-safe environment. Avoid exposing the device to direct sunlight, moisture, or extreme temperatures.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
FR104G Overview
Use the download button to access the FR104G schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like FR104,
or try a keyword search, such as Rectifier Diodes
