FS10-12 - XP POWER

FS10-12 Details

• Manufacturer Part Number:

  FS10-12

• Part Life Cycle Code:

  Active

• Package Description:

  PACKAGE-8/7

• ECCN Code:

  EAR99

• Manufacturer:

  XP Power

• YTEOL:

  6

• Analog IC - Other Type:

  DC-DC UNREGULATED POWER SUPPLY MODULE

• Input Voltage-Max:

  12 V

• Input Voltage-Min:

  0.7 V

• Input Voltage-Nom:

  12 V

• JESD-30 Code:

  R-XXMA-X7

• Length:

  57.2 mm

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  7

• Operating Temperature-Max:

  75 °C

• Operating Temperature-Min:

  -25 °C

• Output Current-Max:

  0.01 A

• Output Voltage-Max:

  1000 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  XMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  CURRENT LIMIT; OVER VOLTAGE; THERMAL; SHORT CIRCUIT

• Ripple Voltage (Main Out):

  3.535 Vrms

• Seated Height-Max:

  13.21 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  UNSPECIFIED

• Terminal Position:

  UNSPECIFIED

• Total Power Output-Max:

  10 W

• Trim/Adjustable Output:

  YES

• Width:

  28.5 mm
