FS100R17KS4F - Infineon

FS100R17KS4F Details

• Manufacturer Part Number:

  FS100R17KS4F

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Pin Count:

  23

• ECCN Code:

  EAR99

• Manufacturer:

  Infineon Technologies AG

• YTEOL:

  0

• Case Connection:

  ISOLATED

• Collector Current-Max (IC):

  100 A

• Collector-Emitter Voltage-Max:

  1700 V

• Configuration:

  3 BANKS, SERIES CONNECTED, CENTER TAP, 2 ELEMENTS WITH BUILT-IN DIODE AND THERMISTOR

• Gate-Emitter Voltage-Max:

  20 V

• JESD-30 Code:

  R-XUFM-X23

• Number of Elements:

  6

• Number of Terminals:

  23

• Operating Temperature-Max:

  150 °C

• Package Body Material:

  UNSPECIFIED

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Polarity/Channel Type:

  N-CHANNEL

• Power Dissipation-Max (Abs):

  960 W

• Surface Mount:

  NO

• Terminal Form:

  UNSPECIFIED

• Terminal Position:

  UPPER

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Transistor Application:

  POWER CONTROL

• Transistor Element Material:

  SILICON

• Turn-off Time-Nom (toff):

  515 ns

• Turn-on Time-Nom (ton):

  141 ns

• VCEsat-Max:

  4.7 V
