FS200R12N3T7 - Infineon

FS200R12N3T7 Details

• Manufacturer Part Number:

  FS200R12N3T7

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Hungary

• ECCN Code:

  EAR99

• Manufacturer:

  Infineon Technologies AG

• YTEOL:

  4

• Case Connection:

  ISOLATED

• Collector Current-Max (IC):

  200 A

• Collector-Emitter Voltage-Max:

  1200 V

• Configuration:

  BRIDGE, 6 ELEMENTS WITH BUILT-IN DIODE AND THERMISTOR

• Gate-Emitter Thr Voltage-Max:

  6.45 V

• Gate-Emitter Voltage-Max:

  20 V

• JESD-30 Code:

  R-XUFM-X35

• Number of Elements:

  6

• Number of Terminals:

  35

• Operating Temperature-Max:

  175 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  UNSPECIFIED

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Polarity/Channel Type:

  N-CHANNEL

• Reference Standard:

  IEC-60747, 60749, 60068; IEC-61140; UL RECOGNIZED

• Surface Mount:

  NO

• Terminal Form:

  UNSPECIFIED

• Terminal Position:

  UPPER

• Transistor Application:

  POWER CONTROL

• Transistor Element Material:

  SILICON

• Turn-off Time-Nom (toff):

  444 ns

• Turn-on Time-Nom (ton):

  235 ns

• VCEsat-Max:

  1.8 V
