3 BANKS, SERIES CONNECTED, CENTER TAP, 2 ELEMENTS WITH BUILT-IN DIODE AND THERMISTOR
Gate-Emitter Voltage-Max:
20 V
JESD-30 Code:
R-XUFM-X29
Number of Elements:
6
Number of Terminals:
29
Operating Temperature-Max:
150 °C
Package Body Material:
UNSPECIFIED
Package Shape:
RECTANGULAR
Package Style:
FLANGE MOUNT
Polarity/Channel Type:
N-CHANNEL
Power Dissipation-Max (Abs):
2250 W
Qualification Status:
Not Qualified
Surface Mount:
NO
Terminal Form:
UNSPECIFIED
Terminal Position:
UPPER
Transistor Element Material:
SILICON
Turn-off Time-Nom (toff):
1300 ns
Turn-on Time-Nom (ton):
400 ns
VCEsat-Max:
2.45 V
FS450R17KE3 Frequently Asked Questions (FAQs)
The maximum operating temperature range for the FS450R17KE3 is -40°C to 150°C.
To ensure reliability, it is recommended to follow the thermal design guidelines provided by Infineon, and to consider the thermal resistance of the package and the PCB layout.
The recommended gate drive voltage for the FS450R17KE3 is between 10V and 15V, with a maximum voltage of 20V.
To protect the FS450R17KE3 from overvoltage and overcurrent, it is recommended to use a suitable voltage regulator and overcurrent protection circuitry, such as a fuse or a current sense resistor.
The maximum allowable power dissipation for the FS450R17KE3 is 150W, but this value can be affected by the thermal design and the operating conditions.
