FW248 - Sanyo

FW248 Details

• Manufacturer Part Number:

  FW248

• Part Life Cycle Code:

  Transferred

• Part Package Code:

  SOT

• Package Description:

  SOP-8

• Pin Count:

  8

• ECCN Code:

  EAR99

• Manufacturer:

  SANYO Semiconductor Co Ltd

• Configuration:

  SINGLE WITH BUILT-IN DIODE

• DS Breakdown Voltage-Min:

  45 V

• Drain Current-Max (ID):

  6 A

• Drain-source On Resistance-Max:

  0.034 Ω

• FET Technology:

  METAL-OXIDE SEMICONDUCTOR

• JESD-30 Code:

  R-PDSO-G8

• Number of Elements:

  1

• Number of Terminals:

  8

• Operating Mode:

  ENHANCEMENT MODE

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Polarity/Channel Type:

  N-CHANNEL

• Pulsed Drain Current-Max (IDM):

  24 A

• Qualification Status:

  Not Qualified

• Surface Mount:

  YES

• Terminal Form:

  GULL WING

• Terminal Position:

  DUAL

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON
