G125-MH10805M3-1AD1ADP - Harwin

G125-MH10805M3-1AD1ADP Details

• Manufacturer Part Number:

  G125-MH10805M3-1AD1ADP

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  UK

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.40

• Manufacturer:

  Harwin

• YTEOL:

  7.7

• Board Mounting Option:

  HOLE 0.11

• Body Breadth:

  0.206 inch

• Body Depth:

  0.255 inch

• Body Length:

  0.846 inch

• Connector Type:

  BOARD CONNECTOR

• Contact Arrangement:

  S8P2

• Contact Finish Mating:

  NOT APPLICABLE

• Contact Finish Termination:

  Gold (Au)

• Contact Gender:

  MALE

• Contact Material:

  NOT SPECIFIED

• Contact Pattern:

  RECTANGULAR

• Contact Resistance:

  25 mΩ

• Contact Style:

  RND PIN-SKT

• Durability:

  1000 Cycles

• Filter Feature:

  NO

• Insertion Force-Max:

  2.8 N

• Insulation Resistance:

  1000000000 Ω

• Insulator Material:

  GLASS FILLED POLYETHYLENE

• JESD-609 Code:

  e4

• Mating Contact Pitch:

  0.05 inch

• Mating Contact Row Spacing:

  0.05 inch

• Mixed Contacts:

  YES

• Mounting Option 1:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Number Of PCB Rows:

  2

• Number of Rows Loaded:

  2

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -65 °C

• Option:

  GENERAL PURPOSE

• PCB Contact Pattern:

  RECTANGULAR

• PCB Contact Row Spacing:

  1.25 mm

• Packing Method:

  TR

• Polarization Key:

  POLARIZED HOUSING

• Rated Current (Power):

  10 A

• Rated Current (Signal):

  2.8 A

• Reference Standard:

  UL

• Terminal Length:

  0.151 inch

• Terminal Pitch:

  0.05 mm

• Termination Type:

  SOLDER

• Total Number of Contacts:

  10

• UL Flammability Code:

  94V-0

• Withdrawl Force-Min:

  0.2 N
