G13JPCF - NKK Switches

G13JPCF Details

• Manufacturer Part Number:

  G13JPCF

• Brand Name:

  NKK Switches

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Japan

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.65

• Manufacturer:

  NKK Switches

• YTEOL:

  8

• Actuator Length:

  0.15 inch

• Actuator Type:

  TOGGLE

• Body Breadth:

  4.5 mm

• Body Height:

  5.4 mm

• Bushing Diameter:

  0.157 inch

• Bushing Length:

  0.063 inch

• Contact Current(AC)-Max:

  0.014 A

• Contact Current(DC)-Max:

  0.014 A

• Contact Voltage(AC)-Max:

  28 V

• Contact Voltage(DC)-Max:

  28 V

• Illumination:

  RED AND GREEN LED

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• PCB Hole Count:

  6

• Surface Mount:

  NO

• Switch Action:

  LATCHED

• Switch Function:

  SPDT

• Switch Type:

  TOGGLE SWITCH

• Termination Type:

  SOLDER
