G2R-2-AC120 - OMRON Electronics

G2R-2-AC120 Details

• Manufacturer Part Number:

  G2R-2-AC120

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Reach Compliance Code:

  Compliant

• Country Of Origin:

  Indonesia

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.20

• Factory Lead Time:

  23 Weeks, 3 Days

• Manufacturer:

  OMRON Electronic Components

• YTEOL:

  0

• Additional Feature:

  COIL OPERATE VOLTAGE(AC): 96 V, COIL RELEASE VOLTAGE(AC): 36 V

• Body Breadth:

  13 mm

• Body Height:

  25.5 mm

• Body Length or Diameter:

  29 mm

• Coil Current(AC)-Max:

  0.008 A

• Coil Power:

  900 mW

• Coil Resistance:

  6500 Ω

• Coil Voltage(AC)-Max:

  120 V

• Coil/Input Supply Type:

  AC

• Contact (AC) Max Rating R Load:

  5A@250VAC

• Contact Current(AC)-Max:

  5 A

• Contact Current(DC)-Max:

  5 A

• Contact (DC) Max Rating R Load:

  5A@30VDC

• Contact Voltage(AC)-Max:

  250 V

• Contact Voltage(DC)-Max:

  30 V

• Contact/Output Supply Type:

  AC/DC

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Operate Time:

  15 ms

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -40 °C

• Physical Dimension:

  29mm x 13mm x 25.5mm

• Reference Standard:

  CSA; SEMKO; TUV; UL; VDE

• Relay Action:

  MOMENTARY

• Relay Function:

  DPDT

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  10 ms

• Surface Mount:

  NO

• Termination Type:

  SOLDER
