G2RG-2A4-DC24 - OMRON Electronics

G2RG-2A4-DC24 Details

• Manufacturer Part Number:

  G2RG-2A4-DC24

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  ROHS COMPLIANT

• Reach Compliance Code:

  Unknown

• Manufacturer:

  OMRON Electronic Components

• Body Breadth:

  13.5 mm

• Body Height:

  25.5 mm

• Body Length or Diameter:

  29 mm

• Coil Current(DC)-Max:

  0.34 A

• Coil Operate Voltage(DC):

  19.2 V

• Coil Power:

  800 mW

• Coil Release Voltage(DC):

  2.4 V

• Coil Resistance:

  720 Ω

• Coil Voltage(DC)-Max:

  24 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  8A@380VAC

• Contact Current(AC)-Max:

  8 A

• Contact Current(DC)-Max:

  8 A

• Contact (DC) Max Rating R Load:

  8A@125VDC

• Contact Voltage(AC)-Max:

  380 V

• Contact Voltage(DC)-Max:

  125 V

• Contact/Output Supply Type:

  AC/DC

• Electrical Life:

  10000 Cycle(s)

• Manufacturer Series:

  G2RG

• Mounting Feature:

  THROUGH HOLE-STRAIGHT MOUNT

• Operate Time:

  15 ms

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -40 °C

• Physical Dimension:

  29mm x 13.5mm x 25.5mm

• Reference Standard:

  CSA; UL; VDE

• Relay Action:

  MOMENTARY

• Relay Function:

  DPST

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  5 ms

• Surface Mount:

  NO

• Terminal Finish:

  NOT SPECIFIED

• Termination Type:

  SOLDER
